The Super Max™ 9500 is a rugged system that uses electricity for powering and propane for heating. The machine is perfect for commercial cleaning applications demanding high pressure, temperature, and moderate flow rates.
The 9500, with a pressure level of 2000 PSI, flow rate of 2 GPM, hot water temperature of 210ºF, and steam temperature of 250ºF, delivers excellent cleaning results. The machine's high pressure, stainless steel heater exchange coil converts cold water to hot in 30 seconds.
The power washer features a heavy-duty 3 HP – NEMA engine, which is durable and can withstand the rigors of commercial cleaning.
240V, single phase, 60 Hz is the standard powering method of the versatile machine, however, customers can also place orders for optional configurations, including 220V-240V, single phase, 50 Hz; 220V-240V three phase, 50 or 60 Hz; and 440V, three phase, 50 or 60 Hz; among others available.
Product Specifications
Warranty1 year (limited)Water Pump Warranty5 years (limited)Motor/Engine Warranty2 years (limited)
Pressure
2000 psi
Flow Rate
2 GPM
Temp. Options
cold, hot, wet steam
Steam Temp.
up to 330ºF
Hot Water Temp.
180ºF - 210ºF
Standard Power Method
electric: 230V, single phase, 60 Hz
Optional Power Methods
(call for pricing) 230V, single phase, 50 Hz
Motor Size
heavy-duty 3.0 HP - NEMA
Minimum Generator Size
9000 watts
Gasoline/Diesel Fuel Capacity
N/A
Ignition System
N/A
Power Cords
1
Heating Method
propane
Heating Fuel Capacity
40 lb. empty tank included
Heater Exchange Coil
high-pressure stainless steel
Heater Response Time
converts cold to hot water - approx.30 secs
Operating Time
continuous use
Pump Drive Method
direct drive
Chemical Infusion
yes - siphon type standard
Wand Included
durable 3' trigger wand with quick disconnect
Nozzles Standard
0º (blast), 15º, 25º, 40º, steam nozzles (wet steam output available in all spray patterns)
Pressure Hose
25' high pressure steam hose
Pressure Hose Options
additional/customizable lengths available
Dimensions
23"w. x 30"d. x 45"h.
Weight
250 lbs
Housing
steel - powder-coated, high gloss, chip/chemical resistant
